Thank you for purchasing your decals from Orchard Classic Decals.
Your decal was printed on gloss self-adhesive polymeric vinyl with a white permanent adhesive (low initial tack).
The vinyl is classed as a digital print media, especially for solvent inks.
We print via large-format print and cut machines (ROLAND TRUEVIS) these use solvent inks that are waterproof, and longevity is assured. Please note the decals, once placed on the bike, should be clear-coated with 2k product to protect against petrol spills, sun and general rubbing.
WARNING: Please note: use of chemical cleaners can have a negative impact on any digitally printed solvent decal; please do not apply any chemical cleaners or wipes, just handle the decal with care and avoid getting fingerprints all over them. Always test out the clear coat you are going to use before you spray. I have used 2K clear coat on all the decals produced, but you need to take care. Always read the instructions.
*Please note we have provided a free printed sample for you to test with your clear coat.
Some steps to follow:
When you receive the decal, it will be made up of 3 layers:
1: Carrier
2: Printed vinyl decal
3: Release tap (top layer).
There are a number of different ways to apply your decal, and YouTube has many guides. I will explain the way we do it in most cases:
l Tools needed:
l Scalpel/blade
l Smoothing tool (credit card should do)
l Kitchen roll
l Water spray (the type for misting indoor plants) filled up with just two drops of washing-up liquid.
l Hot air gun/hair dryer (I would steer clear of the hot air gun in reality, as it can be very destructive if you are not used to the process – stick with a hair dryer; it's much safer
The wet method explained:
This approach sounds strange, especially as we will get the sticky layer wet, but read on; it does work.
Carefully peel back the top layer from the backing carrier; this will bring the decal with it.
Discard the carrier, as it has now done its job.
Apply the water spray solution to the tank (fine mist is good); do not soak it!
The objective is to get it wet enough that the decal will slide around once placed. With the release tape in your hand (this will have the vinyl decal stuck to it), apply the spray to the sticky decal side as well.
If you are happy that you know exactly the position the decal will be placed in, offer up the decal to the tank.
DO NOT STICK DOWN AT THIS STAGE.
Do not apply too much pressure; you will note the decal will move freely around the tank.
DO NOT LET THE DECAL OR TANK DRY OUT!
Once you are happy with the position of the decal, you are now ready to commit.
Starting in the middle of the decal and using your smoothing tool, push out from the middle of the decal towards the edge; this will expel the water as it goes.
Any bubbles can be treated at the end; be sure not to apply too much pressure and prevent creasing the decal. Make sure you give it a few days to fully dry before clear-coating.
If you do crease it, do not panic:
Very gently pull the decal away from the tank; make sure the creased part is part of the vinyl you remove.
Take your hairdryer and carefully warm the vinyl.
The vinyl will go back to its original shape, and you can start that part again.
It is thus important to take five! if you do make a mistake, you can rectify it later on as described.
*Please note if you use a heat gun, take extra care, as too much heat can ruin the decal and even create holes in the vinyl.
Getting rid of bubbles:
Do not get a pin and pierce in the middle!
Use a sharp scalpel and make a slit at the side of the bubble and carefully press out what is causing the bubble, such as air, or it could be water from the wet method approach.
Also have a look on YouTube; there are many guides on there. I always use the method I have explained, and I take my time and do numerous dry runs until I am totally happy with the placement. Sometimes applying heat to the decal will allow it to go round compound curves, but again, go carefully and avoid putting too much pressure or stretching the decal.
My recommendation:
If you have purchased a decal kit with other decals that are smaller in size, it could be a good idea to start with those smaller ones so you get a feeling for the way the vinyl behaves and how you should handle it.
Thank you
Valerie and Andy at Orchard Classic Decals Ltd
